The flange is designed to allow an exhaust with an OD of 3.5" (89mm) to slide inside the flange creating a strong mounting (the flange will require welding to your downpipe)

The flange face has a Male step, which interlocks perfectly with the Garrett turbine outlet flange, creating a secure mount and free of leaks.

CORRECT TIGHTENING OF YOUR V BAND CLAMP

Correct fitting of a V band clamp is vital for correct operation and to ensure you do not suffer premature failure.

 V Band clamps should NOT be tightened excessively. They are designed to pinch the mating flanges together whilst allowing movement through expansion and vibration. Over tightening can damage clamps, flanges and, in worst case, pipe work.

To mount your V Band clamp, butt the mating flanges together and fit clamp. Tighten the clamp to a torque setting of 3.5 Newton Metres (NM). Then, using a rubber mallet, tap around the mating flanges to allow the joints to fully centre and sit without any unequal load. Then increase torque to its final torque setting of 5 Newton Metres (NM).

Further tapping with a rubber mallet to removing any uneven load from the clamp or flange is beneficial whilst checking the torque setting stays at its rating of 5 Newton Metres (NM).

To check if this clamp is for you, measure the INSIDE BORE diameter of the pipe this is to secure and match to the size listed. For example, if your exhaust has a 3.5" bore, then this is for you.

PLEASE MEASURE BEFORE PURCHASE TO AVOID MISTAKES!
